In-Line Valves

inline1

Black line quick release valve (P to T line)
Black hard coated aluminum 7075
Weight: 0,38kg (0,84lbs)
Max working pressure: 700bar (10.000PSI)

Main applications: boom vang fast release, travelers, runners etc.


inline2

Race line quick release (P to T line)
Hard coated aluminum 7075
Weight: 0,235kg (0,52lbs)
Max working pressure: 700bar (10.000PSI)
It can work with pressurized oil tank.

Main applications: boom vang fast release, travelers, runners etc.

inline3

Race line quick release (P to T line) with flow control (you can reduce the release speed)
Hard coated aluminum 7075
Weight: 0,286kg (0,63lbs)
Max working pressure: 700bar (10.000PSI)
It can work with pressurized oil tank.

Main applications: back-up release valve for every cylinders

inline4

Race line by-pass valve (A to B and B to A).
Hard coated aluminum 7075
Weight: 0,260kg (0,57lbs)
Max working pressure: 700bar (10.000PSI)
It can work with pressurized oil tank.

Main applications: fast release for double acting cylinders, traveler fast release

inline5

Race line link valve (A to B and B to A).
Hard coated aluminum 7075
Weight: 0,52kg (1,15lbs)
Max working pressure: 700bar (10.000PSI)
It can work with pressurized oil tank.

Main applications: to put together to pressure line in hydraulic system

inline6

Flow control valve (restriction from A to B. Flow is free from B to A).
Black hard coated aluminum
Weight: 0,18kg (0,39lbs)
Max working pressure: 700bar (10.000PSI)
It can work with pressurized oil tank.


Main applications: release speed control in single and double acting cylinder.

inline7

Max pressure valve (reduce max pressure line)
Hard coated aluminum 7075
Weight: 0,25kg (0,55lbs)
Max working pressure: 700bar (10.000PSI)
It can work with pressurized oil tank.

Main applications: max pressure control in hydraulic system or in single/double acting cylinders.
